Dimensions
Packaging: 740 x 730 x 735 mm (29.1 x 28.7 x 28.9") Rack: 598 x 600 x 639 mm (23.5 x 23.6 x 25.2")
Weight
Packaging: 33.6 kg (74.1 lb) Rack: 28.2 kg (62.2 lb)
Enclosure Material
SPCC steel Door/side panels: 1.2 mm (0.05") Main body: 1.2 mm (0.05") Posts: 2 mm (0.08")
Color
White
Treatment
Powder coating
Rack Features


U Height
12U


Rack Type
4 post, enclosed cabinet


Mounting Hole Type
Square


Adjustable Mounting Depth
Default 448 mm (17.6") Max. 508 mm (20") Adjustable pitch 20 mm (0.08")


Max. Weight Capacity
80 kg (176 lb)


Front Door
Tempered glass Default left-hand outswing, reversible


Side Panels
(2) Solid, removable and lockable


Mounting
Wall mount


Fan Module
✓


Acoustic Noise
≤ 50 dB(A) sound pressure level


Grounding Lugs
✓


Cable Entry Opening
(1) Rear wall: 350 x 100 mm (13.8 x 3.9") (1) Top: 336.5 x 52.5 mm (13.2 x 2.1") (1) Bottom: 336.5 x 52.5 mm (13.2 x 2.1")


Security
(1) Front door lock (4) Side panel locks (2) Keys


Standard
CE; EIA/ECA-310-E; RoHS
NDAA Compliant
✓
